16 Keys 4x4 Matrix - Membrane Type Keypad
This Product is available in Ahmedabad - India Warehouse .
Approx Delivery Time is 2-5 Days.
- Stock: In Stock
- Brand: Import Dukan
- SKU: ID-01-760
₹38
10 or more ₹35
50 or more ₹34
(Excluding 18% GST)
This Matrix Keypad 4 X 4 has 16 buttons, arranged in a telephone-line 3x4 grid with a column of 4 characters (A, B, C, and D). The keys are connected into a matrix, hence only 8 microcontroller pins (4-columns and 4-rows) are required to scan the pad.
This 16-button keypad provides a useful human interface component for microcontroller projects. Convenient adhesive backing provides a simple way to mount the keypad in a variety of applications.
Features:
- 5 pins 2.54mm pitch connector, 4x 4type 16 keys.
- Ultra-thin design & adhesive backing provides easy integration to any project.
- This allows a microcontroller to ‘scan’ the 8 output pins to see which of the 16 buttons is being pressed.
- Excellent price-performance ratio.
- Easy communication with any microcontroller.
- The sticker can peel off for adhesive mounting.
- Used widely in industrial and home electronic equipment, instrument, etc.
Application:
- Arduino projects
- Security systems.
- Menu selection.
- Data entry for embedded systems.
12 Keys 3x4 Matrix - Membrane Type Keypad - Buy Now
Package Content:
1 x 16 Keys 4x4 Matrix - Membrane Type Keypad
Technical | |
Contact Resistance | 500 Ω |
Dielectric Strength | 250VRms |
Insulation resistance | 100 MΩ |
Operating Voltage | 35 V |
Operating current | 0.1 A |
Length | 16.5 cm |
Height | 0.1 cm |
Width | 7 cm |
